The HPE DL380 Gen9 configure to order base server that includes the motherboard only and can be configured to your needs.
- Part Number: 826682-B21
- Manufacturer: HPE
Processor:
- Processor Type: Intel Xeon E5-2620V4 / 2.1Ghz
- Max Turbo Frequency: 3Ghz
- Processor Cores: 8-Cores
- QuickPath Interconnect Speed: 8Gt/s
- Processors Currently Installed: 1
- Max Processors: 2
- Processor Features: Hyper-Threading Technology, Intel Turbo Boost Technology 2
Cache Memory:
- Cache Memory Type: Smart Cache
- Cache Size: 40Mb
- Cache per Processor: 20Mb
Memory:
- Currently Installed: 16 Gigabytes
- Max Memory Size: 384 Gigabytes
- Technology: DDR4 SDRAM - Advanced ECC
- Memory Speed: 2133Mhz
- Form Factor: DIMM 288-Pins
- Memory Features: Registered, Dual Rank, Quad Channel Memory, HP Smart Memory
Hard Drive Storage:
- Hard Drives Currently Installed: None
- Optical Drive Type: DVD-RW SATA
Storage Controller:
- Storage Controller: Smart Array P440AR
- Buffer Size: 2GB
- Controller Interface: 12GBp/s SAS / 6GBp/s SATA
- Ports: Pci-E 3.0 X8 (Pci-E X8)
- Total Physical Drives: 26
- Logical Drives: 64 Logical Drives
- RAID Support: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
Networking:
- Ethernet Ports: 2 x 10 Gigabit Ethernet
- Ethernet Controller: HP 331I
- Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
- Remote Management Controller: Integrated Lights-Out 4
- Features: Wake on LAN, PXE Support
Power Supplies:
- PSU Type: Hot-Pluggable, Redundant
- Power Redundancy Scheme: 1+1
- Currently Installed: 1
- Max Supported Power Supplies: 2
- Nominal Voltage: AC 120/230V
- Wattage: 500 Watts
- Features: 80 Plus Certification: 80 Plus Platinum
- Efficiency: 94%
Dimensions
- Width: 17.5 Inches
- Depth: 26.7 Inches
- Height: 3.4 Inches
- Weight: 32.5 Pounds
ServerParts4Less offers a 1 Year Warranty on this Product.
