767032-B21 HPE ProLiant DL380 Gen9 24 Bay SFF CTO Server

HPE ProLiant DL380 Gen9 server chassis that includes 24 x 2.5 inch Small Form Factor drive bays that can be configured to order. The 767032-B21 can be expanded with scalable processors, up to 768GB total memory capacity (768GB LRDIMM, 384GB RDIMM), supports 24 x hard disk drives and two power supply units.

• Part Number: 767032-B21
• Product Type: Gen9 HPE ProLiant DL380 Server
• Manufacturer: HPE

Processors:

• Processors Currently Installed: 0
• Max Processors: 2
• Processor Scalability: Scalable

Memory:

• Memory Currently Installed: 0
• Maximum Memory Size: 768GB
• Memory Type: DDR4 SDRAM
• Form Factor: 288-Pin DIMM
• Memory Supported: 384GB Registered (RDIMM)/768GB Load Reduced (LRDIMM)

Storage:

• Hard Drives Installed: 0
• Max Hard Drives: 24
• Storage Controller Type: 1 x RAID Integrated
• Controller Interface: SATA-600
• Storage Controller Name: HPE Dynamic Smart Array B140i
• Channel Quantity: 10
• RAID Level: RAID 0, RAID 1, RAID 5, RAID 10

Networking and Communications:

• Networking Type: Integrated
• Interface (Bus) Type: PCIe x2
• Ethernet Port: 4 X Gigabit Ethernet
• Ethernet Controller: HPE 331i
• Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management Controller: Integrated Lights Out 4

Expansion:

• Drive Bays: 24 in Total/24 Free x Hot-swap 2.5 inch SFF
• Processor Sockets: 2 in total
• Memory: 24 x DIMM 288-Pin
• 2 x Pcie 3.0 X16 - Half-length, Full-height (X8 Mode)
• 1 x Pcie 3.0 X8 - Half-length, Full-height
• 1 x MicroSd Card (internal)

Interfaces & Ports:

• 4 X Lan (gigabit Ethernet) - Rj-45
• 1 X Hp Ilo - Rj-45
• 1 X Vga
• 5 X Usb 3.0 (1 Front, 2 Rear, 2 Internal)

Power Supply:

• PSU Currently Installed: 0
• Max Supported PSUs: 2
• Device Type: Hot-pluggable
• Power Redundancy: Optional

Dimensions & Weight:

• Width: 17.5In
• Depth: 26.7In
• Height: 3.4In
• Weight: 32.5Lbs
