HP 3.5-Inch SAS/SATA Hot-Swap Drive Tray for ProLiant G5/G6/G7 (464507-001) is a genuine HP server drive carrier designed to securely mount 3.5-inch Large Form Factor (LFF) SAS or SATA hard drives in compatible HP ProLiant servers and storage systems. It is a standard hot-plug carrier used across numerous ProLiant G5, G6, and G7 platforms. The part is also associated with 335536-001.
-
Part Number: 464507-001
-
Manufacturer: HP / Hewlett-Packard
-
Product Type: Hot-Swap / Hot-Plug Hard Drive Tray / Caddy
-
Form Factor: 3.5-inch Large Form Factor (LFF)
-
Supported Drive Interface: SAS / SATA
-
Drive Compatibility: 3.5-inch LFF HDDs and compatible SSDs
-
Carrier Type: Standard LFF Hot-Plug Carrier
-
Installation: Internal server drive bay
-
Hot-Swap Support: Yes, when installed in a compatible HP hot-plug drive cage/backplane
-
Primary Application: Mounting and securing 3.5-inch SAS/SATA drives in HP ProLiant servers
-
Compatible Server Generations: HP ProLiant G5, G6 and G7
-
Compatible Systems: Includes compatible DL160, DL165, DL180, DL320, DL360, DL370, DL380, DL385, ML150, ML310, ML330, ML350, ML370 and other ProLiant systems using this standard LFF carrier.
-
Compatible Storage Systems: HP D2600, D6000, MSA60, M6612 and other compatible storage enclosures.
-
Related Part Number: 335536-001
-
Related Part: 464507-002 is also listed as a related carrier number.
-
Included Hardware: Drive mounting screws; your specified configuration includes screws. Some listings of the tray alone are supplied without screws, so contents can vary by seller/configuration.
-
Material: Metal carrier with plastic components
